KT-100B/200B
Features
Pocket size, easy to operate
Automatic Probe Zero Calibration
Automatic Probe identification
Suitable for various materials such as steel, stainless steel, aluminum, glass,polystyrene, polyethylene
Average calculation of max 9 readings
Limits setting Low-High
Standard 5.0MHz transducer included, optional transducers 7.5MHz, 2.0MHz, 5.0MHz high temperature
Sound velocity range 1000 up to 9999m/s
Display resolution selectable at 0.1mm/0.01 inches and 0.01mm/0.001 inches
Memory of eadings with location number
Technical Specification
KT-100B | KT-200B | |
Display: 128×64 with backlight | √ | √ |
Measuring range : 0.65-400mm (0.025-15.78inch) (range depends on probe-material combination) | √ | √ |
Velocity rate : 1000-9999m/s (0.0393-0.3936inch/us) | √ | √ |
Average mode: 2 to 9 times average measurement | √ | |
Limit setting: With Low-High indication and alarm | √ | |
Calibration : Auto | √ | √ |
| Display Resolution: 0.01mm(0.001inch) for thickness up to 99.99mm (3.936 inch) 0.1mm(0.01inch) for thickness above 99.99mm (3.93 inch) | √ | √ |
Measuring units: mm/inch | √ | √ |
Memory: Memory of max. 5000 readings with location number | √ | |
Data output: USB to PC | √ | |
Surface temperature: -15℃ to +150℃ (special probes available) | √ | √ |
Battery indicator : Low battery voltage indicator | √ | √ |
Power supply : AAA dry cell 1.5V (2 pcs) | √ | √ |
Dimensions: 115 × 64 × 27mm | √ | √ |
Weight: 220g including batteries | √ | √ |
